Walrus Audio - 900-1087US - Canvas 5 Pedal Power Supply
The Canvas Power 5 has 5 isolated power outputs delivering up to 500mA of clean power at 9v. One of the outlets is variable voltage, letting you switch between 9v, 12v, and 18v for powering high-voltage pedals.
Features:
- Supplies clean, quiet, and isolated power for your favorite pedals and effects
- 4 x 9V outlets and 1 variable 9V/12V/18V outlet — 500mA per outlet
- Slim design and screw inserts (M3) make for easy mounting beneath most popular pedalboards
- Includes mounting brackets for pedalboards with elevated surfaces, such as Pedaltrain products
Specifications:
- Type: Pedalboard Power Supply
- Inputs: 24V DC 4A (AC adapter included)
- Outputs: 4 x 9V DC 500mA, 1 x 9V/12V/18V DC 500ma, 1 x 24V DC pass thru
- Maximum Output Current: 500mA total
- USB: 1 x USB-C (5V, 1.5A out)
- Connectivity: 2.1mm barrel
- Isolated Output: Yes
- Height: 1"
- Width: 5.23"
- Depth: 2.12"
- Weight: 0.41 lbs.
- Manufacturer Part Number: 900-1087US
