Yamaha - DXL1K - Powered Speaker - 1100W

Yamaha - DXL1K - Powered Speaker - 1100W

The DXL1K is a column-type powered speaker with a slim body and powerful sound. It can be used as the main speaker in a compact PA system, and is also perfect for use as an extension of a STAGEPAS 1K mkII system.

Despite its lightweight and compact cabinet construction, the DXL1K features a high-output 1100W amplifier powering a high-frequency array speaker system with 10 x 1.5-inch drivers and a large 12-inch subwoofer, producing best-in-class sound pressure levels of up to 125 dB SPL.

Offering an impressive 170° horizontal and 30° vertical coverage, the DXL1K delivers clear, high-quality sound consistently throughout a wide area.

The DXL1K is perfect for situations that require one or more wide dispersion speaker systems. When used with an outboard mixer, the simplicity of the DXL1K makes deployment fast and easy. The DXL1K can also be used along with the STAGEPAS 1K MKII when a stereo system is desired. Simply run a single cable from the STAGEPAS 1K MKII to easily link the units. The DXL1K is the only powered loudspeaker with this form factor available in the market. It offers superior audio performance that is easy to deploy.

Specifications:

System Type: Powered subwoofer with a line array speaker
Frequency Response (-10 dB): 37 Hz - 20 kHz
Coverage Angle (Horizontal x Vertical): 170° x 30°
Crossover Frequency: 240Hz
Maximum Output Level (Measured peak、IEC noise@1m): 125 dB SPL
Power Requirements:
J: 100V, 50/60Hz
CHN: 220 - 230V, 50/60Hz
K: 220 - 230V, 60Hz
BRA: 110V/220V, 60Hz
UEBT: 110 - 120V, 60Hz, 220 - 240V, 50/60Hz
INA: 220V, 50Hz
Power Consumption: 25 W (Idle), 91 W (1/8 power)
Dimensions (W x H x D): System (maximum) 334 x 2,000 x 418 mm
Weight: 23.0 kgThe number of Mixing Channels: 2
Analog Inputs: Mono mic/line x 1 + mono line x 1, LINK IN（MONO）
EQ / Effects: MODE（SPEECH/MUSIC/CLUB）
Outputs: LINK OUT（MONO/R）
Rated Output:
Dynamic: 1,100W（Subwoofer : 500W, Line array speaker : 600W）
Maximum Output:
THD+N=1%, 5kHz: Line array speaker : 250W（4Ω）
THD+N=1%, 100Hz: Subwoofer : 250W（4Ω）
Frequency Response:
1kHz, 20kHz（REF=4kHz）,1W,8Ω: Line array speaker : -3dB, +1dB
40Hz, 5kHz（REF=1kHz）,1W,4Ω: Subwoofer : -3dB, +1.5dB
20Hz, 20kHz（REF=1kHz）,+10dBu,10kΩ: LINK OUT : -2dB, +1dB
20Hz, 20kHz（REF=1kHz）,+10dBu,10kΩ: MONITOR OUT : -2dB, +1dB
THD+N
1kHz 20kHz LPF, 8Ω, Half power: Line array speaker : 0.2 %
1kHz 20kHz LPF, 4Ω, Half power: Subwoofer : 0.2 %
1kHz 20kHz LPF, +10dBu, 10kΩ: LINK OUT : 0.05%
1kHz 20kHz LPF, +10dBu, 10kΩ: MONITOR OUT : 0.05%
Protection
Speaker: DC-fault, Over Voltage
Amplifier: Thermal, Over Current, Integrated Power Limit
Power supply: Thermal, Over Voltage, Under Voltage
Enclosure
Line array speaker : Enclosed
Subwoofer : Bass-reflex type
Speaker Unit
Line array speaker : 1.5” (3.8 cm) Cone x10
Subwoofer : 12” (30 cm) Cone
Nominal Impedance
Line array speaker : 8 Ω
Subwoofer : 4 Ω
Dimensions (W x H x D)
Line array speaker : 67 x 582 x 86 mm
Spacer (each) : 67 x 555 x 86 mm
Subwoofer : 334 x 550 x 418 mm
Weight
Line array speaker : 1.8 kg
Spacer (each) : 0.6 kg
Subwoofer : 20.0 kg
Included in the package
"Power cord x1,
cover x1, Owner's Manual"
