Strymon - Z12A-OR30 - Ojai R30 - High Current DC Power Supply - 5-Output

Strymon - Z12A-OR30 - Ojai R30 - High Current DC Power Supply - 5-Output

Formidably Flexible.
Power your pedals with Ojai R30—the highest horsepower, most technologically advanced effects pedal power supply of its size. You get clean, rock-steady power for your 9V, 12V and 18V effects pedals in a low profile, expandable package, giving you room to grow.

Ojai R30’s dual-stage topology, pre-regulated outputs, optically isolated feedback, and advanced multistage filtering allow your pedals to achieve their highest possible dynamic range.

Features:

Effects pedal power supply for up to 5 pedals
3 x 9V, 500mA outputs
2 x switchable 9V, 12V, or 18V 500mA outputs
5 pedal cables included (2.1mm barrel connectors, right angle to right angle, 18″ length)
Dual-isolated outputs ensure noise-free pedal operation
24-volt through allows the unit to be added to the Zuma or other Ojai supplies
Built for the rigors of the road
Slim dimensions mount easily under a tight pedalboard

Specifications:

• Type: Power Distribution
• Inputs: 24V DC (AC adapter included)
• Outputs: 3 x 9V DC 500mA, 2 x 9V/12V/18V DC 500ma, 1 x 24V DC pass thru
• Maximum Output Current: 2.5A (dependent on voltage)
• Connectivity: 2.1mm barrel
• Isolated Output: Yes
• Height: 1.15"
• Width: 5.1"
• Depth: 2.3"
• Weight: 6 oz.
• Manufacturer Part Number: Z12A-OR30
