Yamaha - DM3S - Digital Mixing Console - 22-Channel

Yamaha - DM3S - Digital Mixing Console - 22-Channel

The word “compact” is often associated with limitations, and in the sound reinforcement world, often implies compromises in functionality, connectivity, or sound quality, and sometimes all three. Until now choosing a compact console has almost invariably been a matter of what you’re willing to sacrifice to get the capabilities you need in the space you have. The new DM3 series of mixing consoles shatters this stereotype, offering superb sound quality, fast and easy setup and operation, and professional-level features for live sound, streaming, and live or home recording and music production—a combination unmatched in any other mixing console this size. In an ever-changing world that constantly presents new challenges as well as opportunities, DM3 mixing consoles give you the power and flexibility to do more with than you ever imagined with a compact digital console.

Features:

• Packs 22 channels into an ultra-compact digital mixer: 16 mono channels, 1 stereo channel, and 2 stereo FX returns
• 9-inch touchscreen and single all-purpose touch-and-turn knob provide easy operation and navigation
• Capable of sampling rates as high as 96kHz
• 6 mono or 3 stereo mixes, 2 matrixes, and 1 stereo bus
• 16 outstanding mic preamps and 8 convenient analog outputs
• Excellent built-in DSP effects
• 18 x 18 USB audio interface for playback and recording
• 2 x 2 recording directly to a USB drive
• DAW remote mode with transport control
• Custom control via OSC, USB-MIDI, and Yamaha's powerful ProVisionaire software applications

Specifications:

• Type: Digital Mixer
• Channels: 22
• Inputs - Mic Preamps: 12 x XLR, 4 x XLR-1/4" combo
• Phantom Power: 16 Channels
• Outputs - Main: 8 x XLR
• Busses/Groups: Internal (1 x stereo, 6 x mix, 2 x FX, 2 x matrix)
• Data I/O: 1 x RJ-45 (LAN)
• Headphones: 1 x 1/4"
• USB: 1 x Type A, 1 x Type B
• Computer Connectivity: USB (18 x 18)
• Faders: 9 x 100mm Motorized Faders
• A/D Resolution: Up to 96kHz
• DAW Control: Yes
• Screen: 9" touchscreen
• Storage: USB slot
• Power Source: 24V DC, 2.5 Power Supply (included)
• Height: 5.5"
• Depth: 17.9"
• Width: 12.6"
• Weight: 14.33 lbs.
• Manufacturer Part Number: DM3S
